You are here: home  > clamp meter & oscilloscope  > NEW UT232 3 phase 4 wire Power Factor clamp Meter
Enlarge NEW UT232 3 phase 4 wire Power Factor clamp Meter

NEW UT232 3 phase 4 wire Power Factor clamp Meter

Payment Terms: T/T,WU
Place of Origin: , China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Means of Transport: Air

NEW UT232 3 phase 4 wire Power Factor clamp Meter

NEW UT232 3 phase 4 wire Power Factor clamp Meter

   skype is amanda924fung

SPECIFICATIONS
Basic Functions
Range
Best Accuracy
AC Voltage
20V/100V/300V/600V
(1.2%+5)
AC Current
40A/100A/400A/1000A
(2%+5)
Active Power
0.01kW-600kW
(3%+5)
Apparent Power
0.01kVA-600kVA
(3%+5)
Reactive Power
0.01kVAr-600kVAr
(4%+5)
Power Factor
0.3~1(Capacitive or Inductive )
(0.02+2)
Phase Angle
0o~360O
1O
Frequency
20Hz-500Hz
√
Active Energy
1~9999 kWh
(3%+2)
Temperature
-50OC~1300OC
-58OF~2372OF

Special Functions
Auto Ranging

√
Single-phase 2-wire

√
3-phase 3-wire

√
3-phase 4-wire

√
True RMS
AC Voltage or Curren
√
Calibration Feature

√
Data Logging
99
√
Data Recall

√
Max/Min Mode

√
Data Hold

√
USB

√
Display Backlight
EL
√
Full Icon Display

√
Sleep Mode

√
Low Battery Display

√
Input Impedance for AC
Voltage Measurement
Around 10MW
√
Max. Display
9999
√
Analogue Bar Graph

√
GENERAL CHARACTERISTICS
Power
1.5V Battery (LR6) x 4
LCD Size
46 mm x 42 mm
Product Color
Red and Grey
Product Net Weight
601g
Product Size
303 x 112 x 39 mm
Standard Accessories
UT232 - Test Lead, Batteries, English Manual, Alligator
Clips, USB Interface Cable, Software, Carrying Bag
Standard Individual Packing
Gift Box
Standard Quantity Per Carton
24 pcs
Standard Carton Measurement
610 x 360 x 305 mm (0.067 CBM Per Standard Carton)
Standard Carton Gross Weight
28kg
