ATTEN ADS1102CAL 100M Hz 1G Digital Oscilloscope 7" LCD

Price:	300.0~320.0 USD
Payment Terms:	T/T,WU
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: ads1102cal

Delivery Date: within 3 working days

Means of Transport: Air

Brand Name: atten

ATTEN ADS1102CAL 100M Hz 1G Digital Oscilloscope 7" LCD

Summery
skype is amanda924fung tel: +86 1500 133 6788

Ultra thin outward appearance design and internationalization research and development idea made ADS1000CAL series products with more powerful performance and more friendly operation.

The ADS1000CAL series product volume exquisite, operation is flexible; Colored TFT LCD display and Pop-up menu pattern manifests its user friendly; Rich trigger ways can meet a user more extensive need; Multiple Languages User Interface will be develop the ADS1000CAL series product international market.

ADS1000CAL Series Characteristic

1. The volume exquisite and it is convenient for carrying;

2. Used Colored TFT LCD, the waveform display is clearer and stable;

3. Dual channel-channel bandwidth 60MHZ-100MHZ;

4. The real time sampling rate is 1GSas;

5. Memory depth of ADS1000CAL is 40Kpts;

6. Trigger Models Edge, Pulse, Video, Slope, Alternative and Delay trigger modes;

7. Unique Digital Filter function and Waveform recorder function;

8. Pass/Fail function;

9. Thirty two parameters Auto measure function;

10. Cursor measure covers Manual mode, Track mode and Auto mode;

11. Channel waveform and its FFT waveform display on split screen;

12. Pop-up Menu display pattern is more convenient for users using it;

13. Multiple Language User Interface;

14. Support multilingual online help system;

Models

Model Index	ADS1102CAL	ADS1062CAL
Bandwidth	100MHZ	60MHZ
Sampling Rate	Single Channel: 1GSa/s; Double Channel: 500MSa/s
Equivalent Sampling Rate	50GSa/s
Memory Depth	Single Channel: 18Kpts; Double Channels: 9Kpts/CH
Rise Time	<3.5ns	<5.8ns
Input Impedance	1M ohm 17pF
Sec/div Range	2.5ns/div-50s/div	5ns/div-50s/div
Display	Color TFT(480*234)7.0" LCD	Color TFT(480*234)7.0" LCD

Common Specifications of ADS1000CAL Series

The Common Specifications Of All ADS1000CAL Series Products
Display	8x18 divides full screen display
Channels	2
Vertical Sensitivity	2mv-10v/div(1-2-5 Sequence)
Vertical Resolution	8bit
Input coupling	DC, AC, GND
Input Max voltage	400V(Vpp)
Trigger Types	Edge, Pulse, Video, Slope, Alternative, Delay
Trigger Modes	Auto, Normal, Single
Trigger Source	CH1, CH2, Ext, Ext/5, AC Line
Save/Recall	Provide two groups reference waveforms, twenty groups capture waveforms and twenty groups setups internal save/recall function and USB flash drive Save/Recall function
Auto Measure Types	Vpp, Vmax, Vmin, Vamp, Vtop, Vbase, Vavg, Mean, Vrms, Crms, ROVShoot, FOVShoot, RPREShoot, FPREShoot, Freq, Period, Rise time, Fall Time, +Width, -Width, +Duty, - Duty, BWid, Phase, FRR, FRF, FFR, FFF, LRR, LRF, LFR, LFF
Cursor measure	Manual, Track, Auto
Sample Types	Real Time, Equivalent Time
Averages	4, 16, 32, 64, 128, 256
Math	+, -, *, /, Invert
FFT	Window: Hanning, Hamming, Blackman, Rectangular
FFT	Sampling Points: 1024 points
XY Mode	Phase Error: +/-3 degrees Support the sampling rate : 25KSa/s~100MSa/s (in a 1-2-5 sequence)
Display Model	Main, Window, Window Zoom, Roll, X-Y
Menu Display	2Sec, 5Sec, 10Sec, 20Sec, Infinite
Skin	Classical, Modern, Tradition, Succinct
Display Language	Simplified Chinese, Traditional Chinese, English, Arabic, French, German, Russian, Spanish, Portuguese, Japanese, Korean
Power Source Voltage	100-240VAC, 47HZ-440HZ, 50VA Max, CATII
Size and Weight	339mm x 110.5mm x148.5mm, about2.4kg
USB Host	Support USB flash drive storage
USB Device	Support PictBridge compatible printers and PC Remote control RS-232
Accessories	(1:1, 10:1)Problex2, EasyScope Computer Software System, Power Cord, USB Cable, User Manual,
Accessories	EasyDsoLib Software Package,
